Type Diameter
(mm)		 Length
(mm)		 Size Connection Suggested
R.P.M		 Feed Speed
(mm/min)
Segmented 20 20 5teeth G1/2" 4400-4900 370-520
Segmented 20 25 5teeth G1/2" 4400-4900 350-500
Segmented 20 30 5teeth G1/2" 4400-4900 330-480
Segmented 20 35 5teeth G1/2" 4400-4900 310-440
Segmented 20 40 5teeth G1/2" 4400-4900 300-400
Segmented 20 45 5teeth G1/2" 4400-4900 250-330
Segmented 20 50 5teeth G1/2" 4400-4900 230-300
Segmented 20 55 5teeth G1/2" 4400-4900 200-280
Segmented 20 60 5teeth G1/2" 4400-4900 100-180
Segmented 24 20 5teeth G1/2" 4200-4600 350-500
Segmented 24 25 5teeth G1/2" 4200-4600 330-480
Segmented 24 30 5teeth G1/2" 4200-4600 310-460
Segmented 24 35 5teeth G1/2" 4200-4600 290-420
Segmented 24 40 5teeth G1/2" 4200-4600 280-380
Segmented 24 45 5teeth G1/2" 4200-4600 230-310
Segmented 24 50 5teeth G1/2" 4200-4600 200-280
Segmented 24 55 5teeth G1/2" 4200-4600 180-260
Segmented 24 60 5teeth G1/2" 4200-4600 80-160
Other specifications are available upon request.
